Stability Chamber Manufacturer
Medical Refrigerator
Home Medical Refrigerator

Biomedical Pharmaceutical Vaccine Medical Refrigerator

Biomedical Pharmaceutical Vaccine Medical Refrigerator

The medical refrigerator is mainly used to store medicines, reagents, vaccines, biological products, blood products, etc., with a temperature range of 2-8°C, professional medical grade refrigerator.



Model: 250BC~2000BC

Temperature Control: Temperature Fluctuation ≤ ±1℃ ,Temperature Deviation ≤ ±2.0℃

Installed Power: AC220V±10% 50HZ

Environment temperature: +5~35℃

Optional: Data storage and printing.SMS Alarm(With power off alarm)

TEMP Range: 2℃~8℃

  • Item No. :

    XCH 250BC~2000BC
  • Origin :

    China

FEATURES

  • STAINLESS STEEL STAINLESS STEEL

    The liner is made of mirror stainless steel 304

  • REAL-TIME ALARM REAL-TIME ALARM

    Upper and lower limit deviation alarm of temperature and humidity

  • 1 YEAR WARRANTY 1 YEAR WARRANTY

    All machines come with a 1-year limited warranty and engineer remote support.

  • HIGH SENSITIVITY HIGH SENSITIVITY

    Capacitive humidity sensor with high sensitivity.

Medical refrigerator, Biomedical Pharmaceutical Vaccine Refrigerator by cooling system, digital temperature control system, air circulation system, temperature sensor, etc. It mainly used to put the medicine in and adjust the temperature according to the required settings.save drugs, reagents, vaccines, biological products and blood products, etc.



Model: 250BC~2000BC

Temperature Control: Temperature Fluctuation ≤ ±1℃ ,Temperature Deviation ≤ ±2.0℃

Installed Power: AC220V±10% 50HZ

Environment temperature: +5~35℃

Optional: Data storage and printing.SMS Alarm(With power off alarm)

TEMP Range: 2℃~8℃







Refrigeration System

• The imported brand fully enclosed compressor, long-term use, stable performance
• Fluorine-free environmental refrigerant, Microchannel heat transfer technology, High efficiency,Greatly reduce energy consumption.

• Germany famous brand EBM fan, Reliable performance.

Control System

• High precision microcomputer temperature control system, High sensitivity temperature sensor is built into the chamber, Ensure stable internal temperature.
• Whole machine optimized design, Lower noise.

Safety System


• Multi-protection : Compressor overheating, overpressure, overload protection and fan overheating protection.
• Multi-Alarm: Perfect sound and light alarm system,Article reserves more safety

Structure System


• Adopt the latest efficient airway system, better uniformity.
• Inner wall material is stainless steel, The out shell is plastic sprayed steel plate.
• Polyurethane integral foam, good insulation performance, more energy saving.

Model & Parameters:

MODEL TEMP RANGE CAPACITY INTERNAL DIMEN (mm) EXTERNAL DIMEN
W×D×H (mm)
POWER TRAY
XCH-250BC 2 - 8℃ 250L 600×500×830 760×870×1650 0.3KW 3
XCH-400BC 2 - 8℃ 400L 600×700×950 760×1060×1750 0.4KW 3
XCH-500BC 2 - 8℃ 500L 680×680×1070 840×1050×1850 0.5KW 4
XCH-800BC 2 - 8℃ 800L 1200×490×1360 1360×850×1960 0.6KW 4
XCH-1000BC 2 - 8℃ 1000L 1400×510×1400 1560×870×1980 0.7KW 4
XCH-2000BC 2 - 8℃ 2000L 1500×970×1380 1670×1340×1990 1.0KW 4
250BC,400BC,500BC are single door,800BC,1000BC,2000BC are double door.
