From syringes, vaccines to pacemakers, the medical industry needs to understand the limitations of temperature, use and storage, and the manufacturing and research and development of products need to be strictly controlled. XCH Biomedical provide various environmental test chamber and stability chamber for stability testing and storage of products or tools in the medical field to ensure effectiveness and reliability.
The XCH-3000SD Double Door Medicine Drug Stability Environmental Testing Chamber, using imported high-quality components and manufacturing technology, with Medicine Stability Chamber stable and reliable performance, suitable GMP certified users
Model: XCH-800SD-3000SD
TEMP Range: 10~65℃
TEMP Fluctuation: ＜±0.5℃
TEMP Deviation: ＜ ±1.0℃
Humidity Range: 20 ～ 95%
Humidity Deviation:＜ ±3%RH
Capacity: 800L~3000L
Environment temperature: +5 ～ 35℃
The multi-chamber Stability Chamber, Temp Only or Temp/RH. Adopts quality imported components and manufacturing process, with stable and reliable performance, independent control and climatic test of three boxes and temperature and humidity control of A, B and C boxes.
Model: XCH-430SD
TEMP Range: 15~65℃
Fluctuation: ＜±0.5℃
TEMP Deviation: ＜ ±1.0℃
Humidity Range: 20 ～ 95%
Humidity Deviation:＜ ±3%RH
Capacity: 430L~830L
Environment temperature: +5 ～ 35℃
The XCH-320SD medical stability testing chamber Medicine Stability Chamber, two boxes are independently controlled, climatic test, CSD series, A box has temperature, the three functions of humidity and light can be equipped with near-ultraviolet lamps to meet the requirements of the guidelines for the stability test of the 2020 edition of the Pharmacopoeia; Box B only controls and records.
Model: XCH-320 - 620SD
Temperature Range: 10~65℃
Temperature Fluctuation: ＜±0.5℃
Temperature deviation: ＜±1.0℃
Humidity Range: 20~95%RH
Humidity deviation: ＜ ±3%RH
Power: AC 220V±10% 50HZ
Environment temperature: +5 ～ 35℃
The single door low temperature stability chamber, using advanced high-quality components and manufacturing technology, stable and reliable performance, suitable for GMP certified users. Creates a temperature, humidity, light environment for low temperature test chamberevaluation. Suitable for accelerated testing, long-term testing, wet test, and strong light irradiation test.
Temperature Control: Temperature Fluctuation ＜ ±0.5℃
Temperature Deviation＜ ±1.0℃
Humidity Control: Humidity Fluctuation ≤ ±3%RH
Humidity Deviation ≤ ±3%RH
Meet a criterion : Meet ICHQ1A(R2)、Chinese Pharmacopoeia 2020 edition.
Installed Power: AC220V±10% 50HZ
Environment temperature: +5~35℃
SMS alarm: Optional
XCH-150TPS medicine Photostability Test Chamber is equipped with visible light and near-ultraviolet lamp tube, Medicine Stability Chamber can independently control the type of light source, and can print and record visible light illumination and near-ultraviolet radiation in real time. Visible light and near-ultraviolet can be directly set, automatically adjusted and precisely controlled.
Model: XCH 150-500TPS/LTPS
Temp.Range: 15℃ - 50℃
Temperature Fluctuation:＜±1℃
Temperature deviation:＜ ±2.0℃(SAME LEVEL)
Light Range: Visible light range: 100 ~ 8000LUX; Total illumination should not be less than 1.2 x 10^6Lux·hr
UV range: NUV range: 0.84 ~ 5w/m squared; The near-UV energy is no less than 200w•hr/㎡
UV wavelength: NUV wavelength: 320 ~ 400nm;
Environment temperature: +5 ～ 35℃
The XCH-8000SD Series Walk-In Stability test Chamber, newly airway system designed achieves uniform of temperature and humidity form different parts inside the chamber. The inner wall and duct plate are made of stainless steel 304. Observation window of hollow tempered glass with electrothermal film.
Model: XCH 8000/40000LTPS
Temperature Range: 20~ 45℃
Temperature Fluctuation：≤ ±0.5℃
Temperature Deviation：≤ ±1.0℃
Humidity Range：20/40～80%RH(or 20～80%RH）);
Humidity Deviation：≤ ±3.0%RH
Test Points Optional：40℃ /75%RH、25℃ /60%RH、30℃ /65%RH（40℃ /25%RH、25℃ /40%RH、25℃ /60%RH）
Low Temperature Laboratory: 2 ～ 8℃
This 150L temperature and humidity test chamber, high quality stability chamber, using advanced high-quality components and manufacturing technology, stable and reliable performance, suitable for GMP certified users. Creates a temperature, humidity, light environment for drug, medicine and other products fields stability evaluation. Suitable for accelerated testing, long-term testing, wet test, climatic test and strong light irradiation test.
Temperature Control:Temperature Fluctuation ≤ ±0.5℃
Temperature Deviation ≤ ±1.0℃
TEMP Range:10~65℃
Humidity Range:20~95%
Fluctuation＜±3.0%RH
Environment temperature:+5~35℃
XCH JSB Series is a temperature & humidity chamber with high and low temperature Chamber. Through the test and detection, so as to judge whether the performance of the product meets the design requirements for testing.
Model: XCH-JSB
Temp.Range:-40 - 150℃
Humi.Range: 20 - 98% RH
Environment temperature: +5 ～ 35℃
Temperature Fluctuation: ＜±0.5℃
Temperature deviation: ＜±2.0℃
Humidity deviation: ＜ ±5%RH(Humidity deviation ≤ 75%RH)
Power: AC 220V±10% 50HZ
XCH-9270GHP Water jacketed incubator, Dedicated temperature controller, the temperature control accuracy error is small.Optional UV sterilization system can effectively kill the floating bacteria in the circulating air in the box。
Used for bacterial incubation, cultivation, ferment and other thermal experiments on hygiene, medicine, biochemistry, industry and agricultural science.The water jacketed incubator is an essential equipment for scientific research laboratories.
Model: 9050GHP-9760GHP
Temperature Fluctuation ≤ ±0.3℃
Temperature Uniformity ≤ ±0.5℃（@37℃）
Timing Range: 1-9999min
Power: AC 220V±10% 50HZ
Environment temperature: +5 ～ 30℃
XCH-9052DHP Electric Heating Incubator. Excellent temperature uniformity. Digital bacteriological incubator equipped with a special temperature controller, fast induction, small system error.
The Electric Heating Incubator is widely used for bacteria culture, fermentation and constant temperature test in medical and health, pharmaceutical industry, biochemistry, agricultural science and other scientific research and industrial production departments.
Model: 9052DHP-9602DHP
Temperature Fluctuation ≤ ±0.5℃
Temperature Uniformity ≤ ±1.5℃（@37℃）
Timing Range: 1-9999min
Power: AC 220V±10% 50HZ
Environment temperature: +5 ～ 35℃
Optional: Printer or RS485 interface
XCH-150MJS Mold incubator, Humidity Equipped. 150L capicity, Temperature Range 10-60℃. Equipped with UV germicidal lamp.
Mold incubator is an experimental equipment suitable for cultivating eukaryotic microorganisms such as mold. It is a special constant temperature equipment for water body analysis, BOD detection, mold and other microorganism cultivation.
Model: XCH 150-250MJS
Temp.Range: 10℃～60℃
Temperature Fluctuation: ±2.0℃
Humidity Range: 50-90%RH
Humidity Fluctuation: ±5%RH
Environment Temperature: +5 ～ 35℃
Installed Power: AC220V±10% 50HZ
XCH-150MJ Mold incubator, also known as Mildew incubator. Equipped with UV germicidal lamp, you can choose humidification or no humidification (XCH-MJS series is equipped with humidification function).Mold incubator is an experimental equipment suitable for cultivating eukaryotic microorganisms such as mold. It is a special constant temperature equipment for water body analysis, BOD detection, mold and other microorganism cultivation.
Model: 150MJ-1000MJ
Temp.Range: 0℃～60℃
Deviation: ±1.0℃
Power: AC 220V±10% 50HZ
Environment temperature: +5 ～ 30℃
XCH-70LRH Biochemical Incubator uses the latest air duct system to achieve the best level of uniformity of temperature and humidity in different positions inside the chamber.
The bod cooling incubator Polyurethane foam technology is adopted, good insulation, energy saving. Provides precise temperature control for reliable results in pharmaceutical, industrial testing, food, cosmetics, and microbiological research.
LHR Series Biochemical Laboratory incubators is applied to scientific research and production departments such as environmental protection, sanitation and epidemic prevention, agricultural and livestock aquatic medicine detection and cell culture.
Model: XCH 70-1000LRH
Temp.Range: 0℃～60℃
Temperature Fluctuation: High TEMP ≤ ±0.5℃ ; Low TEMP ≤ ±1.0℃
Uniformity ≤ ±1.5℃ （@25℃）
Environment Temperature: +5 ～ 35℃
Installed Power: AC220V±10% 50HZ
XCH-800LRH Biochemical Incubator uses the latest air duct system to achieve the best level of uniformity of temperature and humidity in different positions inside the chamber.
The bod cooling incubator Polyurethane foam technology is adopted, good insulation, energy saving. Provides precise temperature control for reliable results in pharmaceutical, industrial testing, food, cosmetics, and microbiological research.
LHR Series Biochemical Laboratory incubators is applied to scientific research and production departments such as environmental protection, sanitation and epidemic prevention, agricultural and livestock aquatic medicine detection and cell culture.
Model: XCH 70-1000LRH
Temp.Range: 0℃～60℃
Temperature Fluctuation: High TEMP ≤ ±0.5℃ ; Low TEMP ≤ ±1.0℃
Uniformity ≤ ±1.5℃ （@25℃）
Environment Temperature: +5 ～ 35℃
Installed Power: AC220V±10% 50HZ
XCH-250MR series Medicine Storage Refrigerator is mainly used to save drugs, reagents, vaccines, biological products and blood products, etc., The medical refrigerator for vaccines temperature range is 2-8 ℃, the cooling system, digital temperature control system, air circulation system, temperature sensor, etc.
Model: XCH-250MR-500MR
Temperature Control: Temperature Fluctuation ≤ ±1℃ ,Temperature Deviation ≤ ±2.0℃
Installed Power: AC220V±10% 50HZ
Environment temperature: +5~35℃
Optional: Data storage and printin S Alarm(With power off alarm),Multiple devices can share one mobile card.
TEMP Range: 2℃~8℃
XCH-400MR series Medicine Storage Refrigerator is mainly used to save drugs, reagents, vaccines, biological products and blood products, etc., The medical refrigerator for vaccines temperature range is 2-8 ℃, the cooling system, digital temperature control system, air circulation system, temperature sensor, etc.
Model: XCH-250MR-500MR
Temperature Control: Temperature Fluctuation ≤ ±1℃ ,Temperature Deviation ≤ ±2.0℃
Installed Power: AC220V±10% 50HZ
Environment temperature: +5~35℃
Optional: Data storage and printin S Alarm(With power off alarm),Multiple devices can share one mobile card.
TEMP Range: 2℃~8℃
XCH-500MR series Medicine Storage Refrigerator is mainly used to save drugs, reagents, vaccines, biological products and blood products, etc., The medical refrigerator for vaccines temperature range is 2-8 ℃, the cooling system, digital temperature control system, air circulation system, temperature sensor, etc.
Model: XCH-250MR-500MR
Temperature Control: Temperature Fluctuation ≤ ±1℃ ,Temperature Deviation ≤ ±2.0℃
Installed Power: AC220V±10% 50HZ
Environment temperature: +5~35℃
Optional: Data storage and printin S Alarm(With power off alarm),Multiple devices can share one mobile card.
TEMP Range: 2℃~8℃
The medical refrigerator is mainly used to store medicines, reagents, vaccines, biological products, blood products, etc., with a temperature range of 2-8°C, professional medical grade refrigerator.
Model: 250BC~2000BC
Temperature Control: Temperature Fluctuation ≤ ±1℃ ,Temperature Deviation ≤ ±2.0℃
Installed Power: AC220V±10% 50HZ
Environment temperature: +5~35℃
Optional: Data storage and printing.SMS Alarm(With power off alarm)
TEMP Range: 2℃～8℃
XCH-1000MR series Medicine Storage Refrigerator for vaccines is mainly used to save drugs, reagents, vaccine storage fridge, biological products and blood products, etc., temperature range is 2-8 ℃, the cooling system, digital temperature control system, air circulation system, temperature sensor, etc.
Model: XCH-800MR-2000MR
Temperature Control: Temperature Fluctuation ≤ ±1℃ ,Temperature Deviation ≤ ±2.0℃
Installed Power: AC220V±10% 50HZ
Environment temperature: +5~35℃
Optional: Data storage and printing.SMS Alarm(With power off alarm),Multiple devices can share one mobile card
TEMP Range: 2℃~8℃
XCH-800MR series Medicine Storage Refrigerator for vaccines is mainly used to save drugs, reagents, vaccine storage fridge, biological products and blood products, etc., temperature range is 2-8 ℃, the cooling system, digital temperature control system, air circulation system, temperature sensor, etc.
Model: XCH 800MR-2000MR
Temperature Control: Temperature Fluctuation ≤ ±1℃ ,Temperature Deviation ≤ ±2.0℃
Installed Power: AC220V±10% 50HZ
Environment temperature: +5~35℃
Optional: Data storage and printing.SMS Alarm(With power off alarm),Multiple devices can share one mobile card
TEMP Range: 2℃~8℃
XCH-250FC Ultra Low Temperature medical grade freezer inner tank is made of full-mirror stainless steel 304, which is free of pollution sources and easy to clean; it has an alarm system that meets GMP requirements; it has a data acquisition system that meets GMP requirements. The ultra low lab freezer is equipped with a needle printer and U disk storage as standard. It is suitable for stability test and storage of temperature-sensitive drugs.
Model: 150FC~250FC
Temperature Range: -25℃ ～ -15℃
Temperature Fluctuation ≤ ±0.5℃
Temperature Deviation ＜ ±2.0℃
Installed Power: AC220V±10% 50HZ
Environment temperature: +5~35℃
Capacity: 250L, Temp: -25℃ ～ -15℃
Optional: SMS alarm and data storage system
